ATEK Wi‑Fi Differential Pressure Transmitter -500 to 500 Pa
This ATEK Wi‑Fi differential pressure transmitter is a measurement and transmission device for continuous monitoring of pressure differences between two areas. It logs locally and sends data to the ATEK Cloud platform.
Applications
Features and Benefits
Technical Specifications
What's in the Box
- Differential pressure monitoring
- Hood pressure monitoring in pharmacy
- Sterile preparation areas
- Cleanrooms in pharmacies and laboratories
Features and Benefits
- Secure Wi‑Fi transmission to ATEK Cloud
- Integrated data logger with continuous recording
- Redundant power: 5 V adapter and 3400 mAh rechargeable battery with charging circuit
- Built‑in audible alarm for threshold excursions
- Min/max capture with reset
- Certified sensor calibration
- Continuous differential pressure monitoring
- Enhances safety by flagging pressure deviations
- Prevents cross‑contamination by maintaining adequate differential pressure
Technical Specifications
- Sensor: differential pressure
- Measurement range: -500 to +500 Pa
- Resolution: 0.01 Pa
- Accuracy: ±0.10 Pa
- Long‑term stability: ±0.05 Pa/year
- Connectivity: Wi‑Fi to ATEK Cloud platform
- Power: 5 V DC, 1500 mA adapter; 3400 mAh rechargeable Li‑ion battery; integrated charging circuit
- Alarm: built‑in buzzer
- Data logging: internal storage for uninterrupted recording
- Mounting: installation kit included
- Power cable: 3 m
What's in the Box
- ATEK transmitter
- 5 V power supply with 3 m cable
- Differential pressure sensor
- Installation kit
ATEK-T-WF-DIFFPRES
Data sheet
- Applications
- Clean rooms
- Connectivity
- Cellular
WiFi WPA2-Enterprise 802.1x
